Módulo Cube67 Plus Profinet 56526 Murrelektronik

Código: 56526 Marca: MURRELETRONIK

~~R$ 8.210,90~~ R$ 7.926,00

até 6x de R$ 1.501,95

Qtde: Comprar Estoque: 15 dias úteis

Parcelas
- 1x de R$ 7.926,00 sem juros
- 2x de R$ 4.265,77
- 3x de R$ 2.885,86
- 4x de R$ 2.196,69
- 5x de R$ 1.780,34
- 6x de R$ 1.501,32
Parcelas
- 1x de R$ 7.926,00 sem juros
- 2x de R$ 4.265,77
- 3x de R$ 2.885,86
- 4x de R$ 2.196,69
- 5x de R$ 1.780,34
- 6x de R$ 1.501,32
R$ 7.926,00

DADOS TÉCNICOS

Electrical data | Supply

Operating voltage DC	24 V
Current consumption max.	200 mA
Total current UA max.	8 A
Total current US max.	8 A

Industrial communication

Machine Option Management	yes
Supported protocol	PROFINET

Industrial communication | Bus data

Address range outputs max.	1024 Bytes
Address range inputs max.	1024 Bytes

Industrial communication | Profinet

PROFINET addressing	DCP
PROFINET conformance class	B
PROFINET specification	V2.2

Industrial communication | IO-Link

Number of IO-Link master ports max.	128

Diagnostics

Diagnostic	No voltage, Under voltage
Diagnostic via BUS	per module and channel
Diagnostic via LED	per module and channel
Short circuit diagnosis	yes
LED display	Ethernet connection/data traffic
Overload diagnosis	yes

Device protection | Electrical

Degree of protection (EN IEC 60529)	IP67

Mechanical data

Number extension modules max.	32

Mechanical data | Mounting data

Suitable for mounting type	2-hole screw mounting
Height	151 mm
Width	62 mm
Depth	40,5 mm

Environmental characteristics | Climatic

Operating temperature min.	0 °C
Operating temperature max.	55 °C
Storage temperature min.	-20 °C
Storage temperature max.	75 °C

Conformity

Product standard	EN 61131-2
